D-Link DSL-2750E User Manual

DSL-2750E User Manual
35
The following table describes the parameters of this page.
Field Description
Enabled
To enable WPS function and be able to set the
following settings.
SSID The name of your wireless network.
Select Mode
Select the mode either Registar or Enrollee. When
a router is in Registar mode, the client should be in
Enrollee mode, and vice versa.
Configuration
State
When Configured state is selected, wireless
parameters (for example, the encryption password)
are provided by the CPE in WPS negotiation. When
Unconfigured state is selected, wireless
parameters are provided by the connecting user end
(for example, PC).
Push Button
Press the button, the CPE will connect the station
automaticlly.
Input Station PIN
You need to enter a pin which the Enrollee
generated. Press the button to connect the other
with the pin.
When Registrar mode is chosen, the following page appears. In this condition,
only PIN button can be used.

D-Link DSL-2750E Specifications

ADSL Standards

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	RJ-45 port for 10/100BASE-T Ethernet connection
