D-Link DSL-2760U

D-Link DSL-2760U USER’S MANUAL
57
Security – Mac Filtering
MAC Filtering is only effective on ATM PVCs configured in Bridge mode.
FORWARDED means that all MAC layer frames will be FORWARDED except those matching with any of the specified rules in the following table.
BLOCKED means that all MAC layer frames will be BLOCKED except those matching with any of the specified rules in the following table.
WARNING: Changing from one policy to another of an interface will cause all defined rules for that interface to be REMOVED AUTOMATICALLY! You will need to
create new rules for the new policy.
MAC Filtering Policy For Each Interface:
To change the Policy simply tick the Change check box and click the
Change Policy button.
Choose Add or Remove to configure MAC filtering rules.
