D-Link DSL-2877AL User Manual

D-Link DSL-2877AL Dual Band Wireless AC750 VDSL/ADSL2+ Modem Router User Manual
Section 3 - Web User Interface Configuration
Page 37
ETH Setting
Select Internet Connection Type as Ethernet WAN (NBN/UFB) to configure the
Ethernet setting for the WAN mode.
Service Num：Select the service number to configure.
Enable Virtual Circuit: Enable or disable the PTM interface.
802.1q: Activated or deactivated the 802.1q for the WAN mode.
VLAN ID: Enter the VLAN ID if required by your ISP.
IPV4/IPV6
IP Version：Select the IP version to configure. It includes IPv4, IPv4/IPv6 and
IPv6.
WAN Settings
Select this option to configure the WAN settings including Dynamic IP Address,
Static IP Address, PPPoA/PPPoE and Bridge Mode.
WAN - Dynamic IP Address
Select this option to set static IP information provided to you by your ISP.
MTU: If you experience connection issues, you may need to change the MTU
setting for optimal performance with your specific ISP.
Default Route: Enable or disable default route.
Enable PPPoE Passthrough: Enable or disable PPPoE Passthrough.
IGMP Proxy: Enable or disable IGMP proxy.

D-Link DSL-2877AL Specifications

General

LAN Ports	4 x 10/100Mbps
USB Ports	1 x USB 2.0
Frequency Band	2.4 GHz
WAN Ports	1 x RJ-11 DSL port
Antenna Type	2 External Antennas
Security	WPA, WPA2
Weight	270 grams
