D-Link DSL-3900 User Manual

11D-Link DSL-3900 User Manual
Section 2 - Installation
Connect the supplied power adapter to the modem router and a power outlet, and press the power button. The
device LEDs will light up. Wait approximately three minutes before moving on to step 4.
Caution: Use only the included power adapter with this product.
Plug one end of the supplied Ethernet cable into a yellow Ethernet port on the back of the modem router, and the
other end into the Ethernet port on your computer.
If you are setting up the DSL-3900 using a laptop or mobile device, connect to it using the Wi-Fi network name
and password printed on the label attached to the back of your router.
3
4
DSL-3900
Power
PC
DSL-3900
Power
PC
PC
Phone
Phone

D-Link DSL-3900 Specifications

General

Ethernet WAN	Yes
SIM card slot	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1753 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2
Processor cores	2

Weight and Dimensions

Depth	45.5 mm
Width	258.8 mm
Height	184.1 mm
