5D-Link DSL-3900 User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 Power Port Connector for the supplied power adapter.
2 Power Button Press to power on / power o the device.
3 Gigabit LAN Ports
Connects to network devices such as computers, switches, storage (NAS) devices and
game consoles at speeds of up to 1000 Mbps.
4 Gigabit WAN Port Connect an Ethernet cable that is connected to a WAN or modem here.
5 DSL port Connects to an DSL-enabled telephone line.
6 WPS Button Press to start WPS pairing mode.
7 Wi-Fi Button Press to enable/disable Wi-Fi.
8 Reset Button
To reset the device to its factory default settings, use a paper clip to press and hold the
reset button for 5 seconds.
1
2
3
4
5
6
7
8
