Unied Access Point Administrator’s Guide
Unied Access Point Administrator’s Guide
Page 116
January 2015
Appendix B - Conguration Examples
VAP Conguration from the CLI
1.) Connect to the AP by using Telnet, SSH, or a serial connection.
2.) Enable VAP 1.
set vap vap1 status up
3.) Set the VLAN ID to 2.
set vap vap1 vlan-id 2
Note: The previous command sets the VLAN ID to 2 for VAP 1 on both radios. To set the VLAN
ID for VAP 1 on radio one only, use the following command: set vap 1 with radio wlan0 to
vlan-id 2
.
4.) Set the SSID to Marketing.
set interface wlan0vap1 ssid Marketing
5.) Set the Security Mode to WPA Personal.
set interface wlan0vap1 security wpa-personal
6.) Allow WPA2 clients, and not WPA clients, to connect to the AP.
set bss wlan0bssvap1 wpa-allowed off
set bss wlan0bssvap1 wpa2-allowed on
7.) Set the Cipher Suite to CCMP (AES) only.
set bss wlan0bssvap1 wpa-cipher-tkip off
set bss wlan0bssvap1 wpa-cipher-ccmp on
8.) Set the Pre-shared key.
set interface wlan0vap1 wpa-personal-key JuPXkC7GvY$moQiUttp2
If the shared secret keys includes spaces, place the key inside quotation marks.
9.) Use the following commands to view and verify the settings.
get interface wlan0vap1 detail
get vap vap1 detail
VAP Conguration Using SNMP
1.) Load the DLINK-WLAN-ACCESS-POINT-X600-MIB module.
2.) From the MIB tree, navigate to the objects in the apVap table.
3.) Walk the apVapDescription object to view the instance ID for VAP 1 (wlan0vap1).
VAP 1 on Radio 1 is instance 3.
4.) Use the apVapStatus object to set the status of VAP 1 to up (1).
5.) Use the apVapVlanID object to set the VLAN ID of VAP 1 to 2.
6.) Navigate to the objects in the apIfCong table.
7.) Walk the apIfCongName object to view the instance ID for VAP 1 (wlan0vap1).
VAP 1 on Radio 1 is instance 3.
8.) Set the value of instance 3 in the apIfCongSsid object to Marketing.
9.) Set the value of instance 3 in the apIfCongSecurity object to wpa-personal (3).
10.) Set the value of instance3 in the apIfCongWpaPersonalKey object to JuPXkC7GvY$moQiUttp2, which is the
WPA pre-shared key.
11.) Navigate to the objects in the apRadioBss > apBssTable table.
12.) Walk the apBssDescr object to view the instance ID for VAP 1.
VAP 1 on Radio 1 is instance 1.
13.) Set the value of instance 1 in the apBssWpaAllowed object to false (2).
14.) Set the value of instance 1 in the apBssWpaCipherTkip object to false (2).
15.) Set the value of instance 1 in the apBssWpaCipherCcmp object to true (1).
