Section 8 - Conguring Client Quality of Service (QoS)
Section 8 - Conguring Client Quality of Service (QoS)
This section describes how to congure QoS settings that affect trafc from the wireless clients to the AP. By using the
UAP Client QoS features, you can limit bandwidth and apply ACLs and DiffServ policies to the wireless interface. If a
VAP uses WPA Enterprise security to authenticate clients, you can congure the RADIUS server to provide per-client
QoS information.
This section describes the following features:
•) “Conguring VAP QoS Parameters” on page 88
•) “Managing Client QoS ACLs” on page 89
•) “Creating a DiffServ Class Map” on page 95
•) “Creating a DiffServ Policy Map” on page 100
•) “Conguring RADIUS-Assigned Client QoS Parameters” on page 102
Conguring VAP QoS Parameters
The client QoS features on the UAP provide additional control over certain QoS aspects of wireless clients that
connect to the network, such as the amount of bandwidth an individual client is allowed to send and receive. To control
general categories of trafc, such as HTTP trafc or trafc from a specic subnet, you can congure ACLs and assign
them to one or more VAPs.
In addition to controlling general trafc categories, Client QoS allows you to congure per-client conditioning of various
micro-ows through Differentiated Services (DiffServ). DiffServ policies are a useful tool for establishing general micro-
ow denition and treatment characteristics that can be applied to each wireless client, both inbound and outbound,
when it is authenticated on the network.
From the VAP QoS Parameters page, you can enable the Client QoS feature, specify client bandwidth limits, and
select the ACLs and DiffServ policies to use as default values for clients associated with the VAP when the client does
not have their own attributes dened by a RADIUS server.
To congure the Client QoS administrative mode and to congure the QoS settings for a VAP, click the VAP QoS
Parameters tab.
Figure 58 - Congure Client QoS VAP Settings
Field Description
Client QoS Global
Admin Mode
Enable or disable Client QoS operation on the AP.
Changing this setting will not affect the WMM settings you congure on the QoS page.
Radio For dual-radio APs, select Radio 1 or Radio 2 to specify which radio to congure.
VAP Specify the VAP that will have the Client QoS settings that you congure.
The QoS settings you congure for the selected VAP will not affect clients that access the
network through other VAPs.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
