Figure 110: Traffic Prioritization
Table 93 outlines the VLAN priority and DSCP values.
Table 93: VLAN Priority Tags
VLAN Priority Priority DSCP Value
0Best Effort
0
1 Background 16
2 Background
8
3 Best Effort 24
4 Video 32
5 Video 40
6 Voice 48
7 Voice 56
START
Is VLAN tag?
YES
Take Priority from
DSCP
Is VLAN priority tag
(VLAN id = 0)
Take priority from tag
Is priority tag = 0
NO
Take priority from tag
Take Priority from
DSCP
YES
NO
NO
YES
