5D-Link E15 User Manual
Section 1 - Product Overview
Hardware Overview
Front
1 Status LED This LED indicates the current status of the E15, as detailed on the next page
2
Signal Indicator
LED
The more lit white bars on the Signal Indicator LED, the better the wireless signal to the host network. A
single solid orange LED indicates a weak Wi-Fi signal.
3 WPS Button Press to establish a connection with another WPS compatible device.
2
1
3
