126D-Link ShareCenter DNS-345 User Manual
Section 4 - Conguration
Click the Connect (shown in red)button. The Virtual Volume
connects to the Target (shown in blue) you want to associate to
it. Once its connected, the Volume (shown in green) is created.
When the Volume is created, under Connection Status, you
will notice it say: Connected (shown in red). Also, under Disk
Status, you will notice it say: Running (shown in blue). This
means the Volume is active and working. The Used Size and
Total Size (shown in green) also displays data based on the
amount of space you assigned the Volume.
