D-Link ShareCenter Pulse DNS-320 User Manual

9D-Link ShareCenter Pulse DNS-320 User Manual
Section 3 - Installation

e the hard drives are installed, you can attach the top cover. Click Next to continue.
A standard CAT5E Ethernet cable with a RJ-45 connector is needed to connect your
ShareCenter Pulse to your network. Click Next to continue.

D-Link ShareCenter Pulse DNS-320 Specifications

Power

power supply	External Power Supply
power consumption (normal mode)	15.7 W
power consumption (sleep mode)	8.2 W

Operating Environment

operating temperature	0˚ to 40˚ C (32˚ to 104˚ F)
storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
operating humidity	5% to 90% (Non-condensing)

Ports & Interfaces

ethernet port	10/100/1000 Gigabit Ethernet Port
usb port	1 USB 2.0 Port
supported hard drive type	3.5” Internal SATA (Maximum HDD Capacity: 2 TB for each drive)

Weight and Dimensions

dimensions	146.4 x 115 x 178.5 mm (5.8 x 4.5 x 7.0 inches)
weight	0.85 kg (1.87 lbs)
