Configuration D-Link Web Smart Switch User Manual
7
7
2
2
NOTE: Once the ACL rules conflict, rules with the
smaller rule ID will take higher priority.
NOTE:
Inappropriate design may lead to management
access failure.
The ACL Profile List provides information for configuring ACL Profiles manually. ACL profiles are attached to
interfaces, and define how packets are forwarded if they match the ACL criteria.
ACL > Access Profile List
Figure 4.85 – ACL > ACL Profile List
The contents of Access Profile List table include:
Profile ID: Indicates the profile Identification number. The possible configured profile IDs are 1 to 50, and
any profile ID after 50 is reserved for functional ACL.
Type: The owner type of ACL profile; it can be normal ACL or functional ACL.
Profile Summary: Displays the profile summary.
Click Show Details to see the corresponding ACL’s profile details. The ACL profile details are displayed
below the ACL table. Click Show Rules to see the access rules of the corresponding profile. Click Edit /
New Rules to edit or create an access rule in this profile. To add a new rule, please see Access Rule List in
the next section. Click Delete to remove an access profile. Click Delete All to remove all normal ACL entries.
To manually add a profile, click Add:
