xStack DGS-3400 Series Layer 2 Gigabit Managed Switch CLI Manual
34
D-LINK SINGLE IP MANAGEMENT COMMANDS
Simply put, D-Link Single IP Management is a concept that will stack switches together over Ethernet instead of using
stacking ports or modules. Switches using D-Link Single IP Management (labeled here as SIM) must conform to the following
rules:
•
•
•
•
• A SIM group accepts up to 32 switches (numbered 0-32), including the Commander Switch (numbered 0).
•
•
• SIM allows intermediate devices that do not support SIM. This enables the user to manage a switch that are more than
one hop away from the CS.
•
•
•
•
•
•
•
4. A MS can become a CaS by:
5. The user can manually configure a CaS to become a CS
SIM is an optional feature on the Switch and can easily be enabled or disabled. SIM grouping has no effect on the
normal operation of the Switch in the user’s network.
There are three classifications for switches using SIM. The Commander Switch(CS), which is the master switch of the
group, Member Switch(MS), which is a switch that is recognized by the CS a member of a SIM group, and a
Candidate Switch(CaS), which is a switch that has a physical link to the SIM group but has not been recognized by the
CS as a member of the SIM group.
A SIM group can only have one Commander Switch(CS).
All switches in a particular SIM group must be in the same multicast domain.
There is no limit to the number of SIM groups in the same multicast domain, however a single switch can only belong
to one group.
If multiple VLANs are configured, the SIM group will only utilize the default VLAN on any switch.
The SIM group is a group of switches that are managed as a single entity. The DGS-3400 Series may take on three different roles:
Commander Switch(CS) – This is a switch that has been manually configured as the controlling device for a group, and takes on
the following characteristics:
It has an IP Address.
It is not a Commander Switch or Member Switch of another Single IP group.
It is connected to the Member Switches through its management VLAN.
Member Switch(MS) – This is a switch that has joined a single IP group and is accessible from the CS, and it takes on the
following characteristics:
It is not a CS or MS of another IP group.
It is connected to the CS through the CS management VLAN.
Candidate Switch(CaS) – This is a switch that is ready to join a SIM group but is not yet a member of the SIM group. The
Candidate Switch may join the SIM group through an automatic function of the DGS-3400, or by manually configuring it to be a
MS of a SIM group. A switch configured as a CaS is not a member of a SIM group and will take on the following characteristics:
It is not a CS or MS of another Single IP group.
It is connected to the CS through the CS management VLAN.
The following rules also apply to the above roles:
1. Each device begins in the Candidate state.
2. CS’s must change their role to CaS and then to MS, to become a MS of a SIM group. Thus the CS cannot directly be
converted to a MS.
3. The user can manually configure a CS to become a CaS.
a. Being configured as a CaS through the CS.
b. If report packets from the CS to the MS time out.
6. The CaS can be configured through the CS to become a MS.
After configuring one switch to operate as the CS of a SIM group, additional DGS-3400 switches may join the group by either an
automatic method or by manually configuring the Switch to be a MS. The CS will then serve as the in band entry point for access
to the MS. The CS’s IP address will become the path to all MS’s of the group and the CS’s Administrator’s password, and/or
authentication will control access to all MS’s of the SIM group.
With SIM enabled, the applications in the CS will redirect the packet instead of executing the packets. The applications will
decode the packet from the administrator, modify some data, then send it to the MS. After execution, the CS may receive a
response packet from the MS, which it will encode and send back to the administrator.
227
