D-MAX DCK-500B - How to Use in Detail; Basic Connection Setup

10
3. How to Use in Detail
1). Basic Connection
2 lines (485+, 485-) can be used for data line.
(Ground could be of help when earth is stable, but normally 485+, 485- can be used for data
connection)
485-:
485+:
Sub Keyboard
Main Keyboard
