D-MAX DCK-500B - Quick Reference Guide

45
8. Quick Reference
Operation Function
Function Input
Main Sub
Keyboard [1-64] + [MON] Select Monitor
◎ ◎
Keyboard [1-512] + [CAM] Select Camera
◎ ◎
Power supply ON + [SET] Setting Controller
◎ ◎
[SET]
[SET]+[Joystick Stop]+[Keypad 1~128]+[PST]
[Preset No]+[PST]
[CLR+3sec]+[Keypad 1~128]+[PST]+[ENT]
[CLR+3sec]+[PST]+[ENT]
Start Setup mode for Preset
Run Preset, Preset movement
Deleting each Preset
Clear all Preset Positions
◎ ◎
[SET]+[SWING]
[1/2]+[ENT]
[Keypad1~128]+[ENT]+[Keypad 1~128]+
[ENT]
[Keypad 1~127]+[ENT]
[Keypad 1~64]+[ENT]
[1/2]+[SWING]
Start Setup mode for Swing
Select Pan or tilt swing
Select 2 different preset positions
Set Swing Speed
Set dwell time
Run Pan or tilt swing
Stop Swing
◎
Executable
Not-
Configurable
[SET]+[GROUP]
[Keypad 1~6]+[ENT]
[Keypad 1~64]+[ENT]
[Keypad 1~64]+[ENT]
[Keypad 1~127]+[ENT]
[SET]
[Keypad 1~12]+[GROUP]
[GROUP]/Joystick
Start setup mode for Group
Select Group number
Select Preset point
Set moving speed between Preset positions
Set Dwell time
Confirm Input value
Run Group Surveillance
Stop Group Surveillance
◎
Executable
Not-
Configurable
[SET]+[TOUR]
[Keypad 1~12]+[ENT]←repeat
[SET]
[TOUR]
Start setup mode fro Tour
Set Tour repeatedly
End setup for Tour
Run Tour Sequent surveillance
◎
Executable
Not-
Configurable
[C/P] + [ON/OFF] Turn on/ off CCTV CAMERA power
◎ ◎
[L/P] + [ON/OFF] Turn on/ off CCTV LIGHT power
◎ ◎
