D-MAX DCK-500B - General Specifications

43
7. General Specifications
1). Product Standard
Classification Specification
Output Signal
● RS – 422 ● RS – 485
Communication speed
● Speed 9,600, 4,800, 2,400BPS, No parity, 8Bit data, 1Bit stop
Operation
● Control Pan/Tilt /Zoom lens
● Camera power On/Off , Light power On/Off , AUX On/Off
● Alarm On/Off , Preset set/clear ,OSD
● Control Matrix
● Main / Sub keyboard
Operating Status
(Display)
● Display : LCD Display ( The way to select Menu )
● Input ? : Number input by Key can be outputted.
● Camera : If camera is called input data can be outputted.(1~256)
● Monitor : If monitor is called input data can be outputted1-32)
Sound in Use
● When pressing key : Make a buzz sound for about 0.5seconds.
● When inputting wrong data : Make a buzz sound for 3 times.
● If alarm is sounded when Alarm is on : it keeps making a warning beep
sound
Accessories
● Body of keyboard -1-
● Modular cable(RJ-45cable with 10M long) -1-
● Data junction box -1-
● DC 12V 1.5A Adaptor -1-
2). Controller Specification 3).Junction Box specification
ITEM Specification
In/ Output Terminal Modular jack
Communicate with Junction Box TTL
Operating Temperature
0∼40。C
Storage Temperature
-5∼55°C
Operating Humidity
10∼75%
Storage Humidity
10∼95%
Dimension 390(L)×191(W)×102(H)
Weight Approx. 0.9kg
ITEM Specification
In/output terminal Modular jack
Power supply DC 12V, 1A Adapter
Camera Control RS-485/RS-422
Operating temp.
0∼40。C
Storage temp.
-5∼55°C
Operating humid.
10∼75%
Storage humidity
10∼95%
Dimension 109(L)×66(W)×27(H)
Weight Approx. 0.3kg
