Da-Lite DIRECTOR ELECTROL - Director Electrol Installation; Flat Bracket Mounting Method; Formed Bracket Mounting Method

5
DIRECTOR ELECTROL
®
INSTALLATION
9-1/4"
(SUGGESTED) 3/8"
THREADED ROD (NOT
INCLUDED)
ATTACHED TO
MOUNTING BRACKET
FINISHED
CEILING
SELF-TRIMMING
FLANGE
7-1/4"
8-3/4"
CASE LENGTH
VARIABLE POSITION
MOUNTING BRACKETS
7-1/4"
7-1/4"
6-1/8"
MOTOR END
6-1/8"
ELECTRICAL
JUNCTION BOX
SEE DETAIL A
(SUGGESTED) 3/8"
THREADED ROD
(NOT INCLUDED)
4.59"
7.21"
8.75"
DETAIL A
8.74"
HANGER BRACKET
FLAT BRACKET MOUNTING METHOD
FORMED BRACKET
MOUNTING METHOD
