Page 4
REMOVING THE SPILL TRAY
1. Remove grates, caps and burner rings
2. Using burner tool (86007C) remove brass nut (hold down ring) by
turning counter clockwise
3. Lift burner base out and disconnect electrode wire
4. Remove right and left vent cap
5. Remove front and rear grate supports
5. Lift off top frame
6. Remove control panel cover
Figure 14-1
To Next Page
