Page 14
NO BAKE:
λ Check voltage to bake element. Check across relay board at double line relay
λ “no”and BA relay – should get 240V
λ Check Hi-limits SW to see if tripped or double line relay at NO relay
should have 120V
λ Check for open element or broken or open wire
NO BROIL:
λ Check voltage out of BR relay – it should be 120V
λ Check hi-limit switch
λ Check amperage at glow ignitor – should read 3.2-3.5
λ Check safety valve and wires
NO CONVECTON HEAT:
λ Check CVL relay and double relay NO check across and get 240V
λ Check Hi-limit thermostat
λ Check for open element, open wire or bad connection
NO SELF CLEAN:
λ Check volt age to bake element from BA on relay board and double line relay NO
check across - should get 240V.
λ Check latch to see if locking, check power out of relay board. Door lock relay
should get 120V
λ Check hi-limit switch
NO CONVECTION FAN:
λ Check voltage out of main relay board at CV relay, should get 120V
λ Check fan blade binding on convection element
λ Check for bad connection, burnt or open wires
NO CLOCK DISPLAY:
λ Check line volt age into unit – should be 240V
λ Check at main relay harness going into ERC at points 14 and 15 for 24 VAC
λ If you have 24 VAC at 14 and 15 – replace clock
λ If no voltage at 14 and 15 - check the two wires to see if they are open. If the wires
are ok - replace the relay board.
TROUBLESHOOTING
