DAELIM DELFINO User Manual

[Brake Lever Free play]
Lightly squeeze the brake levers until
tension is felt to check for an appropriate
amount of free play. No free play in the
brake levers or overly loose brake levers
are indication of a problem in the brake
system.
Brake lever Free play: 10~20mm
[Check of Brake Fluid]
This is checked by placing the vehicle on
its main stand on a flat surface. Make sure
that the handle bars are at a horizontal
level. Check to see if the fluid is below the
LOWER level.
If brake fluid is significantly low, this may
indicate that there is leakage in the brake
system. Inspect the brake hose to check for
leaks.
[Air Pressure Check]
Check for an appropriate level of air
pressure by examining how the tire sits on
the ground. If you notice any abnormalities
in the shape of the tire with regard to the
area contacting the ground, use a tire
gauge to check tire pressure and adjust the
tire pressure to the appropriate level.
<Tire Pressure>
26
Brake Inspection
LOWER LEVEL
FREE PLAY FREE PLAY
Tire Inspection
Size
Air Pressure
(kgf/
㎠)
1 person
riding
Front 1.50
100/90-10 56J
100/90-10 56J
1.75
1.50
2.25
Rear
Rear
Front
Front
Rear
2 person
riding
