9
PARTS LOCATION
REAR BRAKE LEVER
RECEIVER(SMART KEY)
FUEL TANK LID
FRONT SEAT
REAR CARRIER
BACK REST
TAIL LIGHT
HEAD LIGHT
FRONT FENDER
FRONT CUSHION
BRAKE DISK
BRAKE CALIPER
MAIN STAND
AIR CLEANER
SIDE STAND
