D1146/D1146TI/DE08TIS
MAINTENANCE MANUAL
11
Printed in Jan. 2001 PS-MMA0415-E1A
(2) DE08TIS (Truck)
1
Magnetic pick-up sensor
12 Cooling fan 21 Exhaust elbow
2 Flywheel housing 13 Cooling fan guide 22 Crank shaft pulley
3 Intake manifold 14 Air compressor pulley 23 Vibration damper
4 Fuel filter 15 Thermostat 24 Mounting bracket
5 Air pipe 16 Water pump 25 Oil cooler
(Intercooler to intake manifold)
17 Alternator 26 Starter relay
6 Fuel injection pipe 18 Air pipe 27 Starter
7 Air compressor
(Turbocharger to intercooler)
28 Breather
8 Air con. compressor 19 Air pipe 29 Water delivery pipe
9 Oil pan
(Air cleaner to turbocharger)
30 Air heater relay
10 Fuel injection pump 20 Turbocharger 31 Cooling water pipe
11 Oil filter
