Daewoo D1146 - Fuel Injection Pump

D1146/D1146TI/DE08TIS
MAINTENANCE MANUAL
44
Printed in Jan. 2001 PS-MMA0415-E1A
z Unscrew two bolts fxing the idle gear,
then remove the idle gear and its pin.
3.1.34. Fuel injection pump
z Disassembly the oil hose for lubrication.
z Remove the bolts and nuts of injection
pump flange.
z Unscrew the injection pump fixing bolts
and remove the injection pump by lifting
it up.
z Remove the bracket fixing bolts of
injection pump, and disassemble by
pulling the injection pump backward.
3.1.35. Water chamber cover
z Unscrew the fixing bolts and remove the
water chamber cover.
z Remove the remnant gasket thoroughly.
3.1.36. Fly wheel
z Remove the flywheel fixing bolts and
disassemble it.
z The bolt removal is done by the reverse
order of assembling and by the steps.
