7. Waveforms of Major Check Method
DHC-XD350
-. Audio Out Signal Waveform
-. DAC Output Signal Waveform
-. Optical Output Audio Data Signal waveform
-. L/R Clock Data Waveform During Normal Play
-. Serial Data Output Waveform During Normal Play
21
TEST POINT : DVD TEST DISC MDVD-W111 TRACK2 COLOR BAR
