15. Electrical Parts List
DHC-XD350
1 TUNER MODULE TU001 9737650501 KST-MV114MA1-0 O O 52 R CHIP HR738 HRFT151JBA 1/10 150 OHM J O
1 PCB FRONT AS 11000 9CDC060900 DV-215 O O 53 R CHIP HR739 HRFT181JBA 1/10 180 OHM J O
2 PCB FRONT B700 9CD6586600 289.5X122.5XT1.6 O O 54 R CHIP HR740~742 HRFT103JBA 1/10 10K OHM J 1608 O O
3 C ELECTRO CE700 CEXP1C470V 16V REM 47MF O O 55 R CHIP HR743~745 HRFT000JBA 1/10 0 OHM J 1608 O O
4 C ELECTRO CE701 CEXP1A221V 10V REM 220MF O O 56 R CHIP HR746~748 HRFT222JBA 1/10 2.2K OHM J 1608 O O
5 C ELECTRO CE702 CEXP1H109V 50V REM 1MF 4*5 O O 57 R CHIP HR750 HRFT562JBA 1/10 5.6K OHM J O
6 C ELECTRO CE703 CEXP1C470V 16V REM 47MF O O 58 IC IC701 1M24C04MN- M24C04MN S0P O O
7 CONN AS CN702 9728815800 #26 UL2547 SHIELD 3P BOARD-IN O O 59 IC RMC IC702 1354HF---- 354HF O O
8 CONN AS CN703 9728814300 #26 8P PITCH 2.0 200MM BOARD IN O O 60 IC IC703 1M38B7---- M38B7-XD300 O O
9 CONN WAFER CW701 9CD6269500 52807-0610 O O 61 JACK J700 9736322800 HTJ-035-18A(KUNMING) O O
10 CONN WAFER CW702 9CD6269500 52807-0610 O O 62 LED LD700 DLTL16KGE- LTL-16KGE(GREEN)PI3.1 O
11 CONN WAFER CW704 9CD6269500 52807-0610 O O 63 LED LD700 DLTL16KEE- LTL-16KEE(RED)PI3.1 O
12 CONN WAFER CW705 9CD6271200 52807-2510 O O 64 TR Q702 TZTA1272Y- KTA1272-Y (AUTO) O O
13 DIODE ZENER DZ700~701 DZTZ4R3B-- MTZ4.3B O O 65 SW TACT SW700~706 5S50101001 KPT-1105A 1C-1P O O
14 FL DISPLAY FL700 DHNA12SM21 HNA-12SM21 O O 66 SW TACT SW707~708 5S50101001 KPT-1105A 1C-1P O
15 CORE RING HB700~701 9CD8603400 74279409 PI8.0X9.5X3.5 O O 67 SW PUSH SW710 5S40101373 SPEA122SC011 O O
16 COIL CHIP HB702~703 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O 68 SW ENCORDER VR700 5SH162401- EC16B24204 24P W/DETENT O
17 COIL CHIP HB705 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O 69 CONN FFC WC700 9728815900 FFC 6P P=1.0X100MM K O O
18 C CHIP CERA HC700~701 HCBK223KBA 50V X7R 0.022MF K 1608 O O 70 CONN FFC WC701 9728816000 FFC 6P P=1.0X150M K O O
19 C CHIP CERA HC702~704 HCBK104KBA 50V X7R 0.1MF K 1608 O O 71 CONN FFC WC702 9728816100 FFC 25P P=1.0X370MM K O O
20 C CHIP CERA HC705~706 HCQK101JBA 50V CH 100PF J 1608 O 72 RESO CERA XC700 5PCSA4R190 CSA 4.19M O O
21 C CHIP CERA HC707 HCBK104KBA 50V X7R 0.1MF K 1608 O O 1 PCB INOUT AS 14000 9CDC061200 DV-215 O O
22 C CHIP CERA HC708~709 HCQK300JBA 50V CH 30PF J 1608 O O 2 PCB INOUT B401 9CD6586800 80X169 O O
23 C CHIP CERA HC710~713 HCBK104KBA 50V X7R 0.1MF K 1608 O O 3 C ELECTRO CE402~403 CEXF1E470V 25V RSS 47MF (5X11) TP O O
24 C CHIP CERA HC711 HCBK104KBA 50V X7R 0.1MF K 1608 O O 4 C ELECTRO CE405~406 CEXF1E470V 25V RSS 47MF (5X11) TP O O
25 DIODE SW CHIP HD700~703 DZDS160--- KDS160 O O 5 C ELECTRO CE407~410 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
26 TR CHIP HQ700~702 TZRC102S-- KRC102S O O 6 C ELECTRO CE411~412 CEXF1E470V 25V RSS 47MF (5X11) TP O O
27 R CHIP HR701~702 HRFT101JBA 1/10 100 OHM J 1608 O O 7 C ELECTRO CE413 CEXF1C471V 16V RSS 470MF (8X12)TP O O
28 R CHIP HR703 HRFT100JBA 1/10 10 OHM J 1608 O O 8 C ELECTRO CE414 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
29 R CHIP HR704~705 HRFT103JBA 1/10 10K OHM J 1608 O O 9 C ELECTRO CE415 CEXF1C471V 16V RSS 470MF (8X12)TP O O
30 R CHIP HR706 HRFT101JBA 1/10 100 OHM J 1608 O O 10 C ELECTRO CE416~417 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
31 R CHIP HR707 HRFT103JBA 1/10 10K OHM J 1608 O O 11 C ELECTRO CE418~425 CEXF1H100V 50V RSS 10MF (5X11) TP O O
32 R CHIP HR708 HRFT101JBA 1/10 100 OHM J 1608 O O 12 C ELECTRO CE426~427 CEXF1E470V 25V RSS 47MF (5X11) TP O O
33 R CHIP HR709 HRFT103JBA 1/10 10K OHM J 1608 O O 13 C ELECTRO CE428 CEXF1C471V 16V RSS 470MF (8X12)TP O O
34 R CHIP HR710~712 HRFT101JBA 1/10 100 OHM J 1608 O O 14 CONN WAFER CW401 9CD6269100 52806-2710 O O
35 R CHIP HR713 HRFT103JBA 1/10 10K OHM J 1608 O O 15 CONN WAFER CW408 9CD6267600 52806-1110 O O
36 R CHIP HR714 HRF8331JCA 1/8 330 OHM J 2012 O O 16 C CHIP CERA HC403 HCBK104KBA 50V X7R 0.1MF K 1608 O O
37 R CHIP HR715~717 HRFT103JBA 1/10 10K OHM J 1608 O O 17 C CHIP CERA HC404 HCQK220JBA 50V CH 22PF J 1608 O O
38 R CHIP HR718~719 HRFT473JBA 1/10 47K OHM J 1608 O 18 C CHIP CERA HC405~406 HCBK104KBA 50V X7R 0.1MF K 1608 O O
39 R CHIP HR720 HRFT100JBA 1/10 10 OHM J 1608 O O 19 C CHIP CERA HC409~410 HCBK104KBA 50V X7R 0.1MF K 1608 O O
40 R CHIP HR721~722 HRFT152JBA 1/10 1.5K OHM J 1608 O O 20 C CHIP CERA HC411~412 HCQK101JBA 50V CH 100PF J 1608 O O
41 R CHIP HR723~727 HRFT101JBA 1/10 100 OHM J 1608 O O 21 C CHIP CERA HC415~416 HCQK101JBA 50V CH 100PF J 1608 O O
42 R CHIP HR728 HRFT151JBA 1/10 150 OHM J 1608 O O 22 C CHIP CERA HC419~420 HCQK101JBA 50V CH 100PF J 1608 O O
43 R CHIP HR729 HRFT101JBA 1/10 100 OHM J 1608 O O 23 C CHIP CERA HC423 HCQK101JBA 50V CH 100PF J 1608 O O
44 R CHIP HR730 HRFT181JBA 1/10 180 OHM J 1608 O O 24 C CHIP CERA HC424 HCBK473KBA 50V X7R 0.047MF K 1608 O O
45 R CHIP HR731 HRFT271JBA 1/10 270 OHM J 1608 O O 25 C CHIP CERA HC425~426 HCBK103KBA 50V X7R 0.01MF K 1608 O O
46 R CHIP HR732 HRFT472JBA 1/10 4.7K OHM J 1608 O O 26 C CHIP CERA HC427~428 HCBK102KBA 50V X7R 1000PF K 1608 O O
47 R CHIP HR733 HRFT103JBA 1/10 10K OHM J 1608 O O 27 C CHIP CERA HC429~430 HCBK103KBA 50V X7R 0.01MF K 1608 O O
48 R CHIP HR734 HRFT333JBA 1/10 33K OHM J 1608 O O 28 C CHIP CERA HC431 HCQK101JBA 50V CH 100PF J 1608 O O
49 R CHIP HR735~736 HRFT562JBA 1/10 5.6K OHM J 1608 O O 29 C CHIP CERA HC432 HCBK103KBA 50V X7R 0.01MF K 1608 O O
50 R CHIP HR737 HRFT103JBA 1/10 10K OHM J 1608 O O 30 C CHIP CERA HC434~435 HCBK103KBA 50V X7R 0.01MF K 1608 O O
51 R CHIP HR738 HRFT562JBA 1/10 5.6K OHM J 1608 O 31 C CHIP CERA HC437~438 HCQK101JBA 50V CH 100PF J 1608 O O
