15. Electrical Parts List
DHC-XD350
LOCATION PART-CODE PART-DESC XD300 XD350PART-DESC NO PART-NAMEXD300 XD350NO PART-NAME LOCATION PART-CODE
32 C CHIP CERA HC439 HCBK103KBA 50V X7R 0.01MF K 1608 O O 84 IC CHIP IC406 1NJM4558M- NJM4558M O O
33 DIODE SW CHIP HD402~404 DZDS160--- KDS160 O O 85 IC TX IC407 1TX0C0805- OC0805-TX O O
34 DIODE SW CHIP HD411~422 DZDS160--- KDS160 O O 86 JACK RCA 9P J401 9736325100 JB090148 (RCA 9P) O O
35 COIL CHIP HL402 HLC479J03A 4.7UH CHIP 2012 O O 87 JACK S-VIDEO J402 9736325200 C5026030 (S-VIDEO+RCA) O O
36 COIL CHIP HL404~418 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O 88 JACK SCART J403 9736324800 21P O O
37 COIL CHIP HL420~424 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O 89 CONN FFC WC400 9728816400 FFC 27P P=1.0X100MM R O O
38 COIL CHIP HL428~429 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O 1 PCB MAIN AS 10000 9CDC060800 DV-215 O O
39 TR CHIP HQ401~402 TZTC3875Y- KTC3875Y O O 2 PCB MAIN B800 9CD6586400 234X208 CEM-3 O O
40 TR CHIP HQ403~404 TZRC107S-- KRC107S O O 3 C ELECTRO CE201~204 CEXF1H100V 50V RSS 10MF (5X11) TP O O
41 TR CHIP HQ405 TZTC3875Y- KTC3875Y O O 4 C ELECTRO CE205~206 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
42 TR CHIP HQ406 TZRC107S-- KRC107S O O 5 C ELECTRO CE215~216 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
43 TR CHIP HQ407 TZRA102S-- KRA102S (10X10)PNP O O 6 C ELECTRO CE217 CEXF1H109V 50V RSS 1MF (5X11) TP O O
44 TR CHIP HQ408 TZRC107S-- KRC107S O O 7 C ELECTRO CE218 CEXF1H108V 50V RSS 0.1MF (5X11) TP O O
45 R CHIP HR401 HRFT472JBA 1/10 4.7K OHM J 1608 O O 8 C ELECTRO CE219~220 CEXF1E101V 25V RSS 100MF (6.3X11) TP O O
46 R CHIP HR403 HRFT221JBA 1/10 220 OHM J 1608 O O 9 C ELECTRO CE221~222 CEXF1H100V 50V RSS 10MF (5X11) TP O O
47 R CHIP HR409~410 HRFT101JBA 1/10 100 OHM J 1608 O O 10 C ELECTRO CE223 CEXF1E470V 25V RSS 47MF (5X11) TP O O
48 R CHIP HR411~414 HRFT104JBA 1/10 100K OHM J 1608 O O 11 C ELECTRO CE224~227 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
49 R CHIP HR415~416 HRFT750JBA 1/10 75 OHM J 1608 O O 12 C ELECTRO CE228~229 CEXF1E470V 25V RSS 47MF (5X11) TP O O
50 R CHIP HR417~418 HRFT104JBA 1/10 100K OHM J 1608 O O 13 C ELECTRO CE230 CEXF1H109V 50V RSS 1MF (5X11) TP O O
51 R CHIP HR419~420 HRFT750JBA 1/10 75 OHM J 1608 O O 14 C ELECTRO CE231 CEYF1A102V 10V 1000MF RSS 10X16 O O
52 R CHIP HR421~422 HRFT104JBA 1/10 100K OHM J 1608 O O 15 C ELECTRO CE232 CEXF1H109V 50V RSS 1MF (5X11) TP O O
53 R CHIP HR423~424 HRFT750JBA 1/10 75 OHM J 1608 O O 16 C ELECTRO CE233 CEXF1E470V 25V RSS 47MF (5X11) TP O O
54 R CHIP HR425 HRFT221JBA 1/10 220 OHM J 1608 O O 17 C ELECTRO CE234 CEXF1H100V 50V RSS 10MF (5X11) TP O O
55 R CHIP HR426 HRFT104JBA 1/10 100K OHM J 1608 O O 18 C ELECTRO CE235~236 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
56 R CHIP HR427~431 HRFT101JBA 1/10 100 OHM J 1608 O O 19 C ELECTRO CE237 CEXF1H100V 50V RSS 10MF (5X11) TP O O
57 R CHIP HR432 HRFT680JBA 1/10 68 OHM J 1608 O O 20 C ELECTRO CE238 CEXF1E470V 25V RSS 47MF (5X11) TP O O
58 R CHIP HR433 HRFT473JBA 1/10 47K OHM J 1608 O O 21 C ELECTRO CE239 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
59 R CHIP HR434 HRFT391JBA 1/10 390 OHM J 1608 O O 22 C ELECTRO CE240~242 CEXF1E470V 25V RSS 47MF (5X11) TP O O
60 R CHIP HR435 HRFT750JBA 1/10 75 OHM J 1608 O O 23 C ELECTRO CE243~244 CEXF1H109V 50V RSS 1MF (5X11) TP O O
61 R CHIP HR436 HRFT332JBA 1/10 3.3K OHM J 1608 O O 24 C ELECTRO CE245~246 CEXF1H479V 50V RSS 4.7MF (5X11) TP O O
62 R CHIP HR437 HRFT680JBA 1/10 68 OHM J 1608 O O 25 C ELECTRO CE801~803 CEYF1V102V 35V RSS 1000MF (13X25) O O
63 R CHIP HR438 HRFT473JBA 1/10 47K OHM J 1608 O O 26 C ELECTRO CE804~805 CEYF1V472V 35V RSS 4700MF (22X40) O O
64 R CHIP HR439 HRFT391JBA 1/10 390 OHM J 1608 O O 27 C MYLAR CM801~812 CMXK1J104J MC 63V 0.1MF J O O
65 R CHIP HR440 HRFT473JBA 1/10 47K OHM J 1608 O O 28 C MYLAR CM813~818 CMXK1J474J MC 63V 0.47MF J O O
66 R CHIP HR441~442 HRFT104JBA 1/10 100K OHM J 1608 O O 29 C MYLAR CM819~830 CMXM2A682J 100V 6800PF J (TP) O O
67 R CHIP HR443~446 HRFT101JBA 1/10 100 OHM J 1608 O O 30 C MYLAR CM831~842 CMXK1J104J MC 63V 0.1MF J O O
68 R CHIP HR447~450 HRFT104JBA 1/10 100K OHM J 1608 O O 31 C MYLAR CM991~993 CMXM2A104J 100V 0.1MF J (TP) O O
69 R CHIP HR451~452 HRFT472JBA 1/10 4.7K OHM J 1608 O O 32 CONN WAFER CW101 9CD6264500 52045-1345 TOP ENTRY O O
70 R CHIP HR453~454 HRFT101JBA 1/10 100 OHM J 1608 O O 33 CONN WAFER CW201 9CD6269100 52806-2710 O O
71 R CHIP HR455~456 HRFT104JBA 1/10 100K OHM J 1608 O O 34 CONN AS CW202 9728811400 P2.0 3P 270MM SHIELD O O
72 R CHIP HR457 HRFT750JBA 1/10 75 OHM J 1608 O O 35 CONN WAFER CW203 9CD6267300 52806-0810 O O
73 R CHIP HR458 HRFT391JBA 1/10 390 OHM J 1608 O O 36 CONN WAFER CW205 9CD6269000 52806-2510 O O
74 R CHIP HR459 HRFT473JBA 1/10 47K OHM J 1608 O O 37 CONN WAFER CW991 9728808400 VH-2A WAFER O O
75 R CHIP HR460 HRFT680JBA 1/10 68 OHM J 1608 O O 38 CONN AS CW993 9728814900 #22 6P P=2.0 150MM O O
76 R CHIP HR461~462 HRFT104JBA 1/10 100K OHM J 1608 O O 39 DIODE DB991 DKBPC806-- KBPC806 O O
77 R CHIP HR463~464 HRFT750JBA 1/10 75 OHM J 1608 O O 40 C CHIP CERA HC201~202 HCQK561JBA 50V CH 560PF J 1608 O O
78 R CHIP HR465~466 HRFT102JBA 1/10 1K OHM J 1608 O O 41 C CHIP CERA HC203~204 HCQK121JBA 50V CH 120PF J 1608 O O
79 R CHIP HR468 HRFT101JBA 1/10 100 OHM J 1608 O O 42 C CHIP CERA HC205~206 HCBK104KBA 50V X7R 0.1MF K 1608 O O
80 IC SWITCH IC401 1NJU7313A- NJU7313A (SW ARRAY) O O 43 C CHIP CERA HC207~208 HCQK101JBA 50V CH 100PF J 1608 O O
81 IC CHIP IC402~403 1NJM4558M- NJM4558M O O 44 C CHIP CERA HC209~210 HCBK104KBA 50V X7R 0.1MF K 1608 O O
82 IC SWITCH IC404 1LA7952--- LA7952 O O 45 C CHIP CERA HC221~222 HCBK103KBA 50V X7R 0.01MF K 1608 O O
83 IC IC405 174HCU04-- 74HCU04 (INVERTER) O O 46 C CHIP CERA HC223 HCBK104KBA 50V X7R 0.1MF K 1608 O O
52
