15. Electrical Parts List
DHC-XD350
LOCATION PART-CODE PART-DESC XD300 XD350PART-DESC NO PART-NAMEXD300 XD350NO PART-NAME LOCATION PART-CODE
47 C CHIP CERA HC224 HCBK105KBA 50V X7R 1MF K 1608 O O 99 R CHIP HR227~228 HRF4220JEA 1/4W 22 OHM J 3216 O O
48 C CHIP CERA HC225~226 HCBK222KBA 50V X7R 2200PF K 1608 O O 100 R CHIP HR229~230 HRFT220JBA 1/10W 22 OHM J 1608 O O
49 C CHIP CERA HC227~231 HCBK104KBA 50V X7R 0.1MF K 1608 O O 101 R CHIP HR234~235 HRFT103JBA 1/10 10K OHM J 1608 O O
50 C CHIP CERA HC232~233 HCQK160JBA 50V CH 16PF J 1608 O O 102 R CHIP HR236 HRFT104JBA 1/10 100K OHM J 1608 O O
51 C CHIP CERA HC234~239 HCBK104KBA 50V X7R 0.1MF K 1608 O O 103 R CHIP HR237~238 HRF4220JEA 1/4W 22 OHM J 3216 O O
52 C CHIP CERA HC240~241 HCQK101JBA 50V CH 100PF J 1608 O O 104 R CHIP HR239~240 HRFT561JBA 1/10 560 OHM J 1608 O O
53 C CHIP CERA HC242~243 HCQK681JBA 50V CH 680PF J 1608 O O 105 R CHIP HR241~242 HRFT104JBA 1/10 100K OHM J 1608 O O
54 C CHIP CERA HC244~245 HCQK471JBA 50V CH 470PF J 1608 O O 106 R CHIP HR243~244 HRFT151JBA 1/10 150 OHM J 1608 O O
55 C CHIP CERA HC246~253 HCBK104KBA 50V X7R 0.1MF K 1608 O O 107 R CHIP HR245 HRFT222JBA 1/10 2.2K OHM J 1608 O O
56 C CHIP CERA HC254 HCQK101JBA 50V CH 100PF J 1608 O O 108 R CHIP HR246~247 HRFT000-BA 1/10 0 OHM 1608 O O
57 C CHIP CERA HC255 HCQK561JBA 50V CH 560PF J 1608 O O 109 R CHIP HR250 HRFT100JBA 1/10 10 OHM J 1608 O O
58 C CHIP CERA HC256 HCQK121JBA 50V CH 120PF J 1608 O O 110 R CHIP HR251~252 HRFT220JBA 1/10W 22 OHM J 1608 O O
59 C CHIP CERA HC257 HCQK221JBA 50V CH 220PF J 1608 O O 111 R CHIP HR253 HRFT103JBA 1/10 10K OHM J 1608 O O
60 C CHIP CERA HC258~260 HCBK104KBA 50V X7R 0.1MF K 1608 O O 112 R CHIP HR254 HRFT105JBA 1/10 1M OHM J 1608 O O
61 C CHIP CERA HC261 HCQK220JBA 50V CH 22PF J 1608 O O 113 R CHIP HR255 HRFT473JBA 1/10 47K OHM J 1608 O O
62 C CHIP CERA HC262~265 HCBK104KBA 50V X7R 0.1MF K 1608 O O 114 R CHIP HR256 HRFT471JBA 1/10 470 OHM J 1608 O O
63 C CERA HC266~267 CCZB1H331K 50V B 330PF K (AXIAL) O O 115 R CHIP HR257~259 HRFT220JBA 1/10W 22 OHM J 1608 O O
64 C CHIP CERA HC801~809 HCBK104KBA 50V X7R 0.1MF K 1608 O O 116 R CHIP HR260 HRFT100JBA 1/10 10 OHM J 1608 O O
65 C CHIP CERA HC811~814 HCBK104KBA 50V X7R 0.1MF K 1608 O O 117 R CHIP HR261~264 HRFT220JBA 1/10W 22 OHM J 1608 O O
66 C CHIP CERA HC816 HCBK104KBA 50V X7R 0.1MF K 1608 O O 118 R CHIP HR265 HRFT473JBA 1/10 47K OHM J 1608 O O
67 C CHIP CERA HC818 HCBK104KBA 50V X7R 0.1MF K 1608 O O 119 R CHIP HR267 HRFT100JBA 1/10 10 OHM J 1608 O O
68 C CHIP CERA HC820~825 HCBK331KBA 50V Y5V 330PF J 1608 O O 120 R CHIP HR268~269 HRFT220JBA 1/10W 22 OHM J 1608 O O
69 CHIP TANTAL CAP HC826~831 HCTAJ105KB TSM1V105ASSR(1UF/35V,3216) O O 121 R CHIP HR270 HRFT100JBA 1/10 10 OHM J 1608 O O
70 DIODE SW CHIP HD201~202 DZDS160--- KDS160 O O 122 R CHIP HR271 HRFT471JBA 1/10 470 OHM J 1608 O O
71 R CHIP HL201~204 HRFT000-BA 1/10 0 OHM 1608 O O 123 R CHIP HR272~274 HRFT220JBA 1/10W 22 OHM J 1608 O O
72 R CHIP HL205~206 HRFT100JBA 1/10 10 OHM J 1608 O O 124 R CHIP HR275~277 HRFT000-BA 1/10 0 OHM 1608 O O
73 R CHIP HL207 HRFT000-BA 1/10 0 OHM 1608 O O 125 R CHIP HR278~280 HRFT220JBA 1/10W 22 OHM J 1608 O O
74 R CHIP HL211~221 HRFT000-BA 1/10 0 OHM 1608 O O 126 R CHIP HR281~282 HRFT561JBA 1/10 560 OHM J 1608 O O
75 R CHIP HL223~225 HRFT000-BA 1/10 0 OHM 1608 O O 127 R CHIP HR283~286 HRFT104JBA 1/10 100K OHM J 1608 O O
76 R CHIP HL229~231 HRFT000-BA 1/10 0 OHM 1608 O O 128 R CHIP HR287~288 HRFT821JBA 1/10 820 OHM J 1608 O O
77 R CHIP HL249~250 HRFT000-BA 1/10 0 OHM 1608 O O 129 R CHIP HR289~292 HRFT103JBA 1/10 10K OHM J 1608 O O
78 R CHIP HL801~803 HRFT000-BA 1/10 0 OHM 1608 O O 130 R CHIP HR293~295 HRFT220JBA 1/10W 22 OHM J 1608 O O
79 TR CHIP HQ201 TZRC231S-- KRC231S O O 131 R CHIP HR296 HRFT104JBA 1/10 100K OHM J 1608 O O
80 TR CHIP HQ203~204 TZRC231S-- KRC231S O O 132 R CHIP HR297 HRFT561JBA 1/10 560 OHM J 1608 O O
81 TR CHIP HQ991 TZRC107S-- KRC107S O O 133 R CHIP HR298 HRFT472JBA 1/10 4.7K OHM J 1608 O O
82 R CHIP HR200 HRFT100JBA 1/10 10 OHM J 1608 O O 134 R CHIP HR299 HRFT122JBA 1/10 1.2K OHM J 1608 O O
83 R CHIP HR201~202 HRFT103JBA 1/10 10K OHM J 1608 O O 135 R CHIP HR300 HRFT333JBA 1/10 33K OHM J 1608 O O
84 R CHIP HR203~204 HRFT122JBA 1/10 1.2K OHM J 1608 O O 136 R CHIP HR301 HRFT100JBA 1/10 10 OHM J 1608 O O
85 R CHIP HR205~206 HRFT183JBA 1/10 18K OHM J 1608 O O 137 R CHIP HR801~812 HRFT000-BA 1/10 0 OHM 1608 O O
86 R CHIP HR207~208 HRFT473JBA 1/10 47K OHM J 1608 O O 138 R CHIP HR813~815 HRFT100JBA 1/10 10 OHM J 1608 O O
87 R CHIP HR209~212 HRFT123JBA 1/10 12K OHM J 1608 O O 139 R CHIP HR816 HRFT103JBA 1/10 10K OHM J 1608 O O
88 R CHIP HR213~214 HRFT224JBA 1/10 220K OHM J 1608 O O 140 R CHIP HR819 HRFT103JBA 1/10 10K OHM J 1608 O O
89 R CHIP HR215~216 HRFT101JBA 1/10 100 OHM J 1608 O O 141 R CHIP HR822~833 HRF4569JEA 1/4W 5.6 OHM J 3216 O O
90 R CHIP HR217 HRFT183JBA 1/10 18K OHM J 1608 O O 142 R CHIP HR834~839 HRF4220JEA 1/4W 22 OHM J 3216 O O
91 R CHIP HR218 HRFT123JBA 1/10 12K OHM J 1608 O O 143 R CHIP HR840 HRFT103JBA 1/10 10K OHM J 1608 O O
92 R CHIP HR219 HRFT104JBA 1/10 100K OHM J 1608 O O 144 R CHIP HR843~845 HRFT103JBA 1/10 10K OHM J 1608 O O
93 R CHIP HR220 HRFT123JBA 1/10 12K OHM J 1608 O O 145 DIODE ZENER CHIP HZ991 DRLZ30B--- RLZ30B O O
94 R CHIP HR221 HRFT224JBA 1/10 220K OHM J 1608 O O 146 DIODE ZENER CHIP HZ992 DRLZ4R7B-- RLZ4.7B O O
95 R CHIP HR222 HRFT101JBA 1/10 100 OHM J 1608 O O 147 IC DDX IC201~202 1STA304A-- STA304A O O
96 R CHIP HR223 HRFT103JBA 1/10 10K OHM J 1608 O O 148 IC IC203~204 1CS4341--- CS4341 (DAC) O O
97 R CHIP HR224~225 HRFT100JBA 1/10 10 OHM J 1608 O O 149 IC AMP(CHIP TYPE) IC205 1BA4560F-- BA4560F O O
98 R CHIP HR226 HRFT331JBA 1/10 330 OHM J 1608 O O 150 IC CHIP IC206 1NJM4558M- NJM4558M O O
