15. Electrical Parts List
DHC-XD350
LOCATION PART-CODE PART-DESC XD300 XD350PART-DESC NO PART-NAMEXD300 XD350NO PART-NAME LOCATION PART-CODE
151 IC REGULATOR IC207 1LD1117S33 LD117AS33TR 3.3V (TO-223) O O 43 R CHIP HR520~532 HRFT100JBA 1/10 10 OHM J 1608 O O
152 IC IC208 1CS4228A-- CS4228A (CODEC) O O 44 R CHIP HR533~537 HRFT330JBA 1/10 33 OHM J 1608 O O
153 IC CHIP IC209~210 1NJM4558M- NJM4558M O O 45 R CHIP HR539 HRFT330JBA 1/10 33 OHM J 1608 O O
154 IC IC211~212 174VHC157M 74VHC157MTC O O 46 R CHIP HR544 HRFT000JBA 1/10 0 OHM J 1608 O O
155 IC IC213 174VHC14MT 74VHCMTC TSSOP O O 47 R CHIP HR545 HRFT681JBA 1/10 680 OHM J 1608 O O
156 IC PWM AMP IC801~803 1STA500--- STA500 O O 48 R CHIP HR546~547 HRFT105JBA 1/10 1M OHM J 1608 O O
157 JACK SPK J801 9736325000 PA1220601P O O 49 R CHIP HR549 HRFT100JBA 1/10 10 OHM J 1608 O O
158 COIL FILTER L801~812 5P8080P220 8080P-13-220K O O 50 R CHIP HR550~552 HRFT102JBA 1/10 1K OHM J 1608 O O
159 CONN FFC WC100 9728816500 FFC 13P P=1.25X100MM R O O 51 R CHIP HR556 HRFT470JBA 1/10 47 OHM J 1608 O O
160 X-TAL XC201 5XE6R1440J 6.144MHZ O O 52 R CHIP HR557~575 HRFT330JBA 1/10 33 OHM J 1608 O O
1 PCB MPEG AS 12000 9CDC061000 DV-215 O O 53 R CHIP HR576 HRFT332JBA 1/10 3.3K OHM J 1608 O O
2 PCB MPEG B501 9CD6586500 150X150 O O 54 R CHIP HR577~578 HRFT330JBA 1/10 33 OHM J 1608 O O
3 C ELECTRO CE506 CEXF1E470V 25V RSS 47MF (5X11) TP O O 55 R CHIP HR580~581 HRFT330JBA 1/10 33 OHM J 1608 O O
4 C ELECTRO CE523 CEXF1E470V 25V RSS 47MF (5X11) TP O O 56 R CHIP HR582 HRFT331JBA 1/10 330 OHM J 1608 O O
5 C ELECTRO CE611~613 CEXF1C471V 16V RSS 470MF (8X12)TP O O 57 R CHIP HR583 HRFT000JBA 1/10 0 OHM J 1608 O O
6 C ELECTRO CE618 CEXF1E470V 25V RSS 47MF (5X11) TP O O 58 R CHIP HR586 HRFT000JBA 1/10 0 OHM J 1608 O O
7 C ELECTRO CE619 CEXF1C102V 16V RSS 1000MF (10X20) TP O O 59 R CHIP HR587 HRFT472JBA 1/10 4.7K OHM J 1608 O O
8 C ELECTRO CE622 CEXF1C471V 16V RSS 470MF (8X12)TP O O 60 R CHIP HR588 HRFT330JBA 1/10 33 OHM J 1608 O O
9 CONN AS CN501 9728815700 ADAPI CABLE 40P 360MM O O 61 R CHIP HR589 HRFT000JBA 1/10 0 OHM J 1608 O O
10 JACK ATAPI CW501 9736324700 40P ATAPI O O 62 R CHIP HR590~591 HRFT103JBA 1/10 10K OHM J 1608 O O
11 CONN WAFER CW503 9CD6267300 52806-0810 O O 63 R CHIP HR592 HRFT472JBA 1/10 4.7K OHM J 1608 O O
12 CONN WAFER CW504 9CD6267400 52806-0610 O O 64 R CHIP HR597 HRFT105JBA 1/10 1M OHM J 1608 O O
13 CONN AS CW507 9728814600 #22 4P P=2.0 200MM O O 65 R CHIP HR604 HRFT750JBA 1/10 75 OHM J 1608 O O
14 CONN WAFER CW508 9CD6267600 52806-1110 O O 66 R CHIP HR606 HRFT750JBA 1/10 75 OHM J 1608 O O
15 C CHIP CERA HC501~526 HCBK104KBA 50V X7R 0.1MF K 1608 O O 67 R CHIP HR607 HRFT102JBA 1/10 1K OHM J 1608 O O
16 C CHIP CERA HC527 HCQK151JBA 50V CH 150PF J 1608 O O 68 R CHIP HR608 HRFT101JBA 1/10 100 OHM J 1608 O O
17 C CHIP CERA HC528 HCQK330JBA 50V CH 33PF J 1608 O O 69 R CHIP HR609 HRFT201JBA 1/10 200 OHM J 1608 O O
18 C CHIP CERA HC534~538 HCQK330JBA 50V CH 33PF J 1608 O O 70 COIL CHIP HR610 HLC479J03A 4.7UH CHIP 2012 O O
19 C CHIP CERA HC539 HCBK104KBA 50V X7R 0.1MF K 1608 O O 71 R CHIP HR611 HRFT000JBA 1/10 0 OHM J 1608 O O
20 C CHIP CERA HC541 HCBK103KBA 50V X7R 0.01MF K 1608 O O 72 R CHIP HR612 HRFT330JBA 1/10 33 OHM J 1608 O O
21 C CHIP CERA HC542~546 HCBK104KBA 50V X7R 0.1MF K 1608 O O 73 R CHIP HR613 HRFT750JBA 1/10 75 OHM J 1608 O O
22 C CHIP CERA HC547 HCBK224KBA 50V X7R 0.22MF K 1608 O O 74 R CHIP HR614 HRFT330JBA 1/10 33 OHM J 1608 O O
23 C CHIP CERA HC549 HCQK220JBA 50V CH 22PF J 1608 O O 75 COIL CHIP HR616 HLC479J03A 4.7UH CHIP 2012 O O
24 C CHIP CERA HC550 HCBK104KBA 50V X7R 0.1MF K 1608 O O 76 R CHIP HR617~621 HRFT301JBA 1/10 300 OHM J 1609 O O
25 C CHIP CERA HC553~555 HCBK104KBA 50V X7R 0.1MF K 1608 O O 77 R CHIP HR622~623 HRFT330JBA 1/10 33 OHM J 1608 O O
26 C CHIP CERA HC574 HCQK150JBA 50V CH 15PF J 1608 O O 78 R CHIP HR624~625 HRFT101JBA 1/10 100 OHM J 1608 O O
27 C CHIP CERA HC576 HCQK150JBA 50V CH 15PF J 1608 O O 79 R CHIP HR626 HRFT402FBA 1/10 4.0K OHM F 1608(1%) O O
28 C CHIP CERA HC578~579 HCQK470JBA 50V CH 47PF J 1608 O O 80 R CHIP HR630~632 HRFT301JBA 1/10 300 OHM J 1609 O O
29 C CHIP CERA HC590 HCBK104KBA 50V X7R 0.1MF K 1608 O O 81 R CHIP HR637 HRFT301JBA 1/10 300 OHM J 1609 O O
30 C CHIP CERA HC607~608 HCBK104KBA 50V X7R 0.1MF K 1608 O O 82 R CHIP HR638~643 HRFT000JBA 1/10 0 OHM J 1608 O O
31 C CHIP CERA HC614~617 HCBK104KBA 50V X7R 0.1MF K 1608 O O 83 R CHIP HR644~646 HRFT104JBA 1/10 100K OHM J 1608 O O
32 C CHIP CERA HC619 HCBK104KBA 50V X7R 0.1MF K 1608 O O 84 IC MPEG DEC IC501 1ES4408FD- ESS4408FD (MPEG DEC) O O
33 C CHIP CERA HC637~640 HCQK560JBA 50V CH 56PF J 1608 O O 85 IC SDRAM IC502~503 1HY57V1616 HY57V1616 O O
34 C CHIP CERA HC645 HCQK560JBA 50V CH 56PF J 1608 O O 86 IC FLASHROM IC505 1M29F080A- STM29F080A O O
35 C CHIP CERA HC673 HCQK560JBA 50V CH 56PF J 1608 O O 87 IC IC506 1M24C04MN- M24C04MN S0P O O
36 C CHIP CERA HC675~676 HCQK100JBA 50V CH 10PF J 1608 O O 88 IC VIDEO ENCODER IC507 1CS4955--- CS4955 O O
37 C CHIP CERA HC679 HCQK100JBA 50V CH 10PF J 1608 O O 89 IC REGULATOR IC509 1A1C1117CY AIC117-CY O O
38 C CHIP CERA HC680~685 HCQK560JBA 50V CH 56PF J 1608 O O 90 IC IC517 174HCU04-- 74HCU04 (INVERTER) O O
39 TR CHIP HQ601~603 TZTA1504S- JTA1504S O O 91 COIL CHIP L501~502 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
40 R CHIP HR501~505 HRFT472JBA 1/10 4.7K OHM J 1608 O O 92 COIL CHIP L503 HLC479J03A 4.7UH CHIP 2012 O O
41 R CHIP HR511~512 HRFT472JBA 1/10 4.7K OHM J 1608 O O 93 COIL CHIP L505 HLC104J01A BEAD 120 OHM 100MHZ 2012 O O
42 R CHIP HR513~519 HRFT470JBA 1/10 47 OHM J 1608 O O 94 R CHIP L506 HRFT561JBA 1/10 560 OHM J 1608 O O
