022-00028AE Operation and Maintenance Manual Inspection, Maintenance and Adjustment 4-21
E: Remote location points.
1. REMOTE FITTINGS FOR LOADER ARM
FOOT ENDS (50 HOUR) (Figure 35 and
Figure 36).
2. REMOTE FITTINGS FOR BUCKET
CYLINDER HEAD (50 HOUR) (Figure 35
and Figure 37).
1
1
2
AJO0150L
Figure 34
Figure 35
