7-4 Specifications
K1000896E Operation and Maintenance Manual
Category Dimension
Overall Length (A) 7,500 mm (24' - 7")
Overall Width (B) 2,740 mm (8' - 12")
Overall Height (C) 3,320 mm (10' - 11")
Bucket Width (D) 2,740 mm (8' - 12")
Wheel Base (E) 3,020 mm (9' - 11")
Tread (F) 2,040 mm (6' - 8")
Ground Clearance (G) 430 mm (1' - 5")
Dump Height, to tooth (H) 2,760 mm (9' - 1")
Dump Distance, to Bucket Edge (I) 1,060 mm (3' - 6")
Minimum Tire Turning Radius (J) 5,166 mm (16' - 11")
Bucket Angle, Raised (a) 46°
Bucket Angle (b), Lowered (at carry) 45°
Bucket Angle (b), Lowered (on ground) 38°
Tire Size
20.5-25-16 PR
20.5R25 (Option)
