VRO Stem Adjustment
With the VRO clamp the handle-
bar can be easily adjusted to t
the rider’s height or desired riding
position by moving it forwards,
backwards, up and down. The fol-
lowing instructions explain how to
adjust the VRO clamp.
WARNING: If you are in
any way unsure of how to
make these adjustments, take
your bike to a qualied bicycle
technician for professional
adjustment.
NOTE: Make sure that the angle
of the handlebar allows you easy
access to the brake levers.
Step 1 - Loosen the bolts of the
VRO clamps with a 5 mm Allen
key.
Step 2 - Adjust the height and po-
sition of the handlebar to achieve
your preferred riding position.
Move the VRO clamp within the
“window of adjustment” - front,
backwards, up, and down.
Step 3 - After establishing the
desired position, tighten the bolts
of the VRO clamps with a torque
of 10 Nm.
WARNING: Make sure that
the outside faces of the
clamps are aligned to the stem
mount T-bar.
