The Dahon Neos Adjustment
The original low-prole Dahon Neos derailleur is spe-
cially designed for small wheels. The Neos allows for
twice as much ground clearance than a conventional
derailleur and the cache technology means that the
derailleur body lies ush underneath the chain stays.
In this way the derailleur body only projects 12 mm
from the chain stays and is much more protected than
a derailleur which protrudes by up to 40 mm. And
the new Neos 2.0 is the next evolutionary step with
upgraded materials and reduced weight.
WARNING: If you are in any way unsure of
how to make these adjustments yourself,
take your bike to a qualied technician for
professional adjustment.
Due to its special design the Dahon Neos derailleur’s
position differs from that of a conventional derailleur.
Compared to a conventional derailleur it is aligned in
the opposite direction, i.e. the adjustment screws and
the wire adjustment bolt are facing forward.
But nevertheless, you can adjust it like any other de-
railleur. Please follow the instructions below.
Conventional DerailleurDahon Neos Derailleur
Wire Adjustment Bolt
Low Adjustment Screw
Wire Fastening Bolt
High Adjustment Screw
Wire Tension
Adjustment Bolt
Adjustment Screws
