DAHON Bicycle - Torque Values - Hubs, Axles, Frame, Fork; Hubs and Axles; Frame and Fork Components

EN
79
Front and Rear Hubs; QR and Nutted Axles
Component in•lbs Newton Meters (Nm) kgf•cm
Freehub body 305~434 34.5~49 35~499
Cassette sprocket lockring; disc brake lockring 260~434 29.4~49 299~499
Front axle nuts 180 20.3 207
Rear axle nuts to frame (non-quick release type wheels) 260~390 29.4~44.1 299~449
Frame and Fork
Component in•lbs Newton Meters (Nm) kgf•cm
BAB lower frame coupling 35 4 40
BAB upper seat binder bolt 35~55 4~6.2 40~63
BB mid seat mast binder bolt 35~55 4~6.2 40~63
Kickstand mounting bolt 60 6.8 69
H2O cage mounting screw 25~35 2.8~4 29~40
Frame front or rear rack braze-on bolt torque 25~35 2.8~4 29~40
Fender to frame mounting bolt torque 50~60 5.6~6.8 58~69
Formulas for converting to other torque designations:
in•lb = ft•lb x 12
in•lb = Nm x 8.851
in•lb = kgf•cm / 1.15
