Kore I-Beam Seat
Adjustment
The Kore I-beam saddle is a revo-
lutionary new saddle system that
cuts down dramatically on weight,
while at the same time allowing
the maximum in saddle adjust-
ability to the rider. The saddle can
be moved forward and backward
on the rail, while the tilt can be
adjusted up or down as well.
WARNING: If you are in
any way unsure of how to
make these adjustments, take
your bike to a qualied bicycle
technician for professional
adjustment.
Step 1 - Loosen the Kore I-Beam
seat rail clamp with a 4mm Allen
wrench.
Step 4 - Adjust the fore and aft
position.
Step 3 - Adjust the tilt of the
saddle.
Step 2 - Fit the saddle onto the
rails.
Step 5 - Tighten the pre-greased
bolts to 85 in/lbs or 9.5 NM.
