419
Please refer to the following sheet for detailed information.
Check the box here to enable tour function.
Here is for you to adjust transparency. The value ranges from 5 to
120s. The default setup is 5s.
Here you can set window mode and channel group. System can
support 1/4/8/9/16/25/36-window according to device channel
amount.
Here you can set motion detect tour/alarm tour window mode.
System supports 1/8-window now.
5.10.5.2.3 Custom Split
From main menu->Setup->System->Display->Custom split, the interface is shown as in Figure 5-118.
Here you can set customized split mode.
Note
This function is for some series products. Please refer to the actual product for detailed information.
Device max supports 5 customized videos.
Figure 5-118
Click and then click to select basic mode
In regular mode, drag the mouse in the preview frame, you can merge several small windows to one
window so that you can get you desired split mode.
After the setup, the selected window has the red frame.
Select the merging window, the frame is red; you can click to cancel the merge to restore regular
mode.
Click OK to exit.
5.10.5.3 RS232
The RS232 interface is shown as in Figure 5-119.
To Next Page
