Dahua Lite NVR2104-4KS2 User Manual

90
The beneficio 1U with 1 PoE port series NVR rear panel is shown as below. See Figure 2-32.
Figure 2-32
The beneficio 1U with 8 PoE ports series NVR rear panel is shown as below. See Figure 2-33.
Figure 2-33
The beneficio 1U with 16 PoE Ports series rear panel is shown as below. See Figure 2-34.
Figure 2-34
Please refer to the following sheet for detailed information.
Name
Function
Power switch
Power on/off button.
Power input port
Input DC 12V/5A.
For beneficio 1U series product only.
Switch power port. Input DC 48//1.04A.
For beneficio 1U with 1 PoE port series product only.
Input AC 100~240V.
For beneficio 1U with 8/16 PoE ports series product
only.
MIC IN
Audio input port
Bidirectional talk input port. It is to receive the analog
audio signal output from the devices such as
microphone, pickup.
