User's Manual
151
Figure 4-49 Privacy masking
Step 2 Configure parameters.
Table 4-15 Privacy masking parameters
Parameter Description
Channel Select a channel.
1, 2, 3, 4
Select
Enable
to enable privacy masking. The number represents
the number of masking areas. You can select a number and drag
masking areas to the screen, and you can also change the size of
areas or drag an area to other place.
You can drag up to 4 masking areas to one channel.
Default Set as device default configuration.
Step 3 Click
Apply
.
4.2.6 Encode
You can set video bit stream and image parameters.
