User's Manual
314
201. Refer to Table 4-63 for detailed information.
Figure 4-201
Table 4-63
Parameter Description
No.
Indicates the number of the currently connected HDD. The asterisk (*)
means the current working HDD.
Device Name Indicates name of HDD.
Physical Position Indicates installation position of HDD.
Properties Indicates HDD type.
Total Space Indicates the total capacity of HDD.
Free Space Indicates the usable capacity of HDD.
Health Status Indicates the health status of the HDD.
S.M.A.R.T View the S.M.A.R.T reports from HDD detecting.
Status Indicates the status of the HDD to show if it is working normally.
4.10.2.4 BPS
Here is for you to view current video bit rate (kb/s) and resolution.
Select
Main Menu
>
MAINTAIN
>
System Info
>
BPS
, the BPS interface is displayed. See Figure 4-
202.
