User's Manual
259
Figure 4-157
Step 2 Draw people counting rule.
1) Click to draw people counting rule.
2) Configure parameters.
Table 4-47
Parameter Description
Name Customize the rule name.
Duration Set the minimum time that the object stays until the alarm is triggered.
Filter target
Click to filter the target. Check the blue wireframe and adjust the
size of the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum size),
that is, when the passing target is smaller than the minimum target or
larger than the maximum target, no alarm will be generated. The
maximum size should not be smaller than the minimum size.
3) Click and hold the left mouse key to draw an area for people counting.
4) Click
OK
.
Step 3 Click in both
Parameters
and
Trigger
columns, and configure parameters.
Table 4-48
Parameter Description
Channel Select a channel from the dropdown list.
Enable Check the box to enable the function.
Rule Type Select a people counting rule type.
Rule
Click
RULE
to set statistics region, name, direction.
