User's Manual
305
Parameter Description
Send Email
Select the check box. When an alarm occurs, the NVR device sends an email
to the set mailbox to notify the user.
You need to set the email first. For details, see "4.11.11 Email".
Record Channel
Select the check box and select the needed recording channel (support
multiple choices). When an alarm occurs, the NVR device activates the
channel for recording.
You need to enable intelligent recording and auto recording first. For
details, see "4.1.4.6 Schedule".
PTZ Linkage
Select the check box and click Setting to select the channel and PTZ action.
When an alarm occurs, the NVR device associates the channel to perform
the corresponding PTZ action. For example, activate the PTZ in channel one
to turn to the preset point X.
●
Tripwire alarm supports to activate PTZ preset point only.
●
You need to set the corresponding PTZ actions first, see "4.4.4 Calling
PTZ Functions".
Tour
Select the check box and select the channel for tour. When an alarm occurs,
the local interface of the NVR device displays the selected channel screen.
●
You need to set the time interval and mode for tour first, see "4.16.2
Tour".
●
After the tour is over, the preview interface is restored to the screen split
mode before the tour.
Snapshot
Select the Snapshot check box to take a snapshot of the selected channel.
To use this function, select
Main Menu
>
CAMERA
>
ENCODE
>
Snapshot
,
in the Mode list, select
Event (Trigger)
.
Log
Select the check box, the NVR device records the alarm information in the
log when an alarm occurs.
Alarm Tone
Check the box and then select the corresponding audio file from the drop-
down list. System plays the audio file when the alarm occurs.
Refer to "4.17.1 File Management" to add audio file first.
Buzzer Select the check box to activate the buzzer when an alarm occurs.
Step 3 Click
Apply
.
