User's Manual
70
I2/NVR21HS-8P-I/NVR21HS-8P-I2 Series
Procedure
Step 1 Loosen the screws of the upper cover and side panel.
Figure 3-7
Step 2 Remove the cover in the direction of the arrow as shown in the figure below.
Figure 3-8
Step 3 Turn over the device, and align the HDD to the four holes of bottom panel, and then fix the
HDD with screws.
Figure 3-9
Step 4 Connect HDD to the device using data cable and power cable.
To Next Page
