314
Parameter
Function
Delete
Click , you can delete the remote connection of the corresponding
channel.
Type
There are two connection types. You can use the network to connect
to the camera or use the WIFI. The means current network
camera connection mode is general; the means current
network camera mode is hotspot.
Delete
Select a device in the Added device list and then click Delete button,
system can disconnect the device and remove it from the Added
device list.
Manual
Add
Click it, the interface is shown as in Figure 5-19. Here you can add
network camera manually.
You can select a channel from the dropdown list (Here only shows
disconnection channel.)
Note:
System supports manufactures such as Panasonic, Sony,
Dynacolor, Samsung, AXIS, Arecont, Dahua and Onvif standard
protocol.
If you do not input IP address here. System uses default IP
192.168.0.0 and system does not connect to this IP.
Can not add two devices at the same time. Click OK button here,
system only connect to the corresponding device of current
channel.
5.8.1.2 Image
Note
Slight difference may be found since the connected network camera may not be same model.
Here you can view device property information. The setups become valid immediately after you set. See
Figure 5-20.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua nvr4208-8p and is the answer not in the manual?

Dahua nvr4208-8p Specifications

General IconGeneral
Operating SystemEmbedded LINUX
IP Camera Input8 channel
Two-way Talk1 channel Input, 1 channel Output, RCA
Interface1 HDMI, 1 VGA
OSDCamera title, Time, Video loss, Camera lock, Motion detection, Recording
Record Interval1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Ethernet1 RJ-45 Port (10/100/1000Mbps)
Max. User Access128 users
Smart PhoneiPhone, iPad, Android
HDD Bays1
Operating Temperature-10°C ~ +55°C (+14°F ~ +131°F)
Main ProcessorDual-core embedded processor
Multi-screen Display1/4/9
Video Detection and AlarmMotion Detection, MD Zones: 396 (22 x 18), Video Loss, Camera Blank
Alarm input4
Relay Output2
CompressionH.265, H.264
Recording ResolutionUp to 8MP
Record ModeManual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Camera Blank, Video Loss)
PoE8 ports (IEEE802.3af/at)
ProtocolsHTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
USB Interface2 USB2.0
Power SupplyAC 100~240V, 50/60 Hz
Power ConsumptionNVR: <10W (without HDD), PoE: Max 25.5W for single port, 130W total
Operating Humidity10%~90% RH
