Dahua NVR4216-16P-4KS2

140
collides with the front panel
3.3.9 NVR42V-8P Series
①Use 4 screws to secure the HDD
②Put the HDD to the HDD box at the front.
③Pull the HDD knob up when you put the HDD
into the box in case the knob buckle may strike
the front panel.
④Put the knob back after you insert the HDD
to the SATA board.
.
3.4 CD-ROM Installation
Please follow the steps listed below.
① Open top cover and then remove the
HDD bracket
② Take off the bottom of the HDD bracket and CD-ROM
bracket.
