375
Figure 5-114
Figure 5-115
Please refer to the following sheet for detailed information.
Select speed dome connected channel.
There are two options: local/remote.
Please select remote type if you are connecting to the network PTZ.
Please select local type if you are using RS485 to the PTZ camera.
Select the corresponding dome protocol such as PELCOD.
Set corresponding dome address. Default value is 1. Please note
your setup here shall comply with your dome address; otherwise
you can not control the speed dome.
Select the dome baud rate. Default setup is 9600.
The value ranges from 5 to 8. Default setup is 8. Please set according
to the speed dome dial switch setup.
