Device Debugging 34
Figure 5-19
Set VTH info.
Be used as a master VTH.
Enter “Room No.” (such as 9901 or 101#0) and press “OK” to save.
“Room no.” shall be the same with “VTH Short No.”, which is set when adding
VTH at WEB interface. Otherwise, it will fail to connect VTO.
In case of extension VTH, room no. shall end with #0. Otherwise, it will fail to
connect VTO.
Be used as an extension VTH.
Press [Master] and switch to “Extension”.
Enter “Room No.” (such as 101#1) and “Master IP” (IP address of master VTH).
“Master Name” and “Master Pwd” are the user name and password of master VTH.
Default user name is admin, and the password is the one set during device
initialization.
(Optional) Press to enable SSH.
After SSH is enabled, the debugging terminal connects VTH through SSH protocol, so
as to operate and debug it.
Press [OK] to save config.
5.1.2.4 SIP Server
Configure SIP server on VTH, and build connection.
At main interface, press [Setting] for more than 6 seconds.
The system pops up “Password” prompt box.
Enter the password set during initialization, and press [OK].
Press [SIP Server].
The system displays “SIP Server” interface, as shown in Figure 5-20.
To Next Page
