Dahua VTO Series Quick Start Guide

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 7
No.
Name
Description
1
Tamper alarm
The VTO would make alarm sound if it is being
removed from the wall by force, and the alarm will
also be sent to the management center.
2
Access output port
See "2.4.1 Access Control Input and Output Port."
3
Ethernet port
Connects to the network with Ethernet cable.
4
Access input port
See "2.4.1 Access Control Input and Output Port."
5
Power port
Inputs 12V DC power to the VTO.
6
Analog signal port
See "2.4.3 Analog Signal Port."
7
RS-485/RS-482 port
See "2.4.2 RS-485/RS-482 Port."
VTO1210C-X
2.3.1 Front Panel
VTO1210C-X
Table 2-5 Front panel description
No.
Name
Description
1
MIC
Inputs audio.
2
Fill light
Provides extra light for the camera.
3
Speaker
Outputs audio.
