Installation 7
3.2.2 Installed in the Wall
Install the mounting box rear cover in the wall. Step 1
Install VTO on the mounting box front cover. Step 2
Fix the VTO to the mounting box front cover by screwing two M3×8 screws into the Step 3
VTO from the bottom of the mounting box front cover.
Put the mounting box front cover (with VTO) into the mounting box rear cover. Step 4
Put waterproof rings to the M8 screws. Step 5
Screw four M8 screws (with waterproof ring) into the mounting box front cover. Step 6
Apply silica gel to gaps between the device and the wall. Step 7
Liquid sodium silicate is recommended.
Installed in the Wall Figure 3-4
