Installer reference guide BRC1E53
7
4P419250-1 – 2015.10
Remote controller installation procedure
3-4-2 Left outlet
P2P1
Indoor unit
Upper case
Lower case
PCB
3-4-3 Top left outlet
Install the attached
wiring retainer to
prevent wiring
pinching as shown
to the left.
P2P1
-Cross-section
Wiring
Upper case
Lower case
Upper case
Wiring retainer
Wiring retainer
Indoor unit
PCB
3-4-4 Upper center outlet
PCB
P2P1
Lower case
Upper case
Wiring retainer
Indoor unit
