Daikin BRC2E61 - Wiring Connections

9
3) Conduct wiring
1.Switchboxandtransmissionwiringarenotattached.
2. Do not directly touch the PCB (Printed Circuit Board).
CAUTION
Wiringspecications
WiringType Sheathed vinyl cord or cable (2 cores) (*1)
WiringSize 0.75~1.25 mm
2
WiringLength Max.500m(*2)
* 1.Somecountriesmayrequireashieldedwiring.
Refer to the installation manual attached to the indoor unit.
* 2.Thiswillbethetotalextendedlengthinthesystemwhendoinggroupcontrol.
Preparethewiringforconnectiontotheremotecontrollerfollowingtheseinstructions.
Approx.10mm
Foreasywiring,itisbetterto
keepapprox.10mmdifference
betweenthelengthof2wires.
Cutting guideline
ofthewiring
Peel the insulator and sheath
Sheathstrippinglength:
• Approx.135mmfortoprightoutlet
• Approx.125mmforrightoutlet
• Approx.105mmforbottomcentreoutlet
Connecttheterminals(P/P1,N/P2)oftheremotecontrollertotheterminals(P1,P2)oftheindoor
unit. (P1 and P2 have no polarities.)
 Top right outlet
P1 P2
Uppercase Lowercase
Indoorunit
