Daikin BRC2E61 - Installation Guide; Location and Wiring Outlet Selection

8
For the installer
5. Remote controller installation procedure
1) Determine where to install the remote controller.
Makesuretofollow“1. Safety precautions”whendeterminingthelocation.
2) Determine the direction of controller wiring outlet
(Top right outlet, Right outlet, Bottom centre outlet).
1) Top right outlet
2) Right outlet 3) Bottom centre outlet
Cutawaythethinarea(hatchedarea)with
nippersorthelikeandthenremoveburrs
withaleorthelike.
Cutawaythethinarea(hatchedarea)with
nippersorthelikeandthenremoveburrs
withaleorthelike.
Cutawaythethinarea(hatchedarea)with
nippersorthelikeandthenremoveburrs
withaleorthelike.
Front side
Front side Front side
Backside
Backside Backside
